| PartNumber | LTM170EU-A01 |
| Značka | Samsung |
| Velikost | 17.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 270 |
| CR | 400:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | SAMSUNG |
| panelový model | LTM170EU-A01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 337.92×270.336 mm |
| obrys | 358.5×296.5×25.4 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 270 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193165% |
| Doba odezvy | 5/20 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | Analog RGB, 27 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
