| PartNumber | COM35H3M10XTC |
| Značka | ORTUSTECH |
| Velikost | 3.5 |
| aplikace | HHP |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 190 |
| CR | 400:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | ORTUSTECH |
| panelový model | COM35H3M10XTC 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 53.64×71.52 mm |
| obrys | 63.5×85×5.53 mm |
| povrch | Hard coating (3H) |
| jas | 190 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 40/60 (Max.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 39 pins |
| vstupní napětí | 3.0V (Typ.) |
| aplikace | HHP |
