| PartNumber | COM35H3P09UTC |
| Značka | ORTUSTECH |
| Velikost | 3.5 |
| aplikace | HHP |
| Rozlišení | 480×640 |
| Složení | LCM |
| Jas | 200 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | ORTUSTECH |
| panelový model | COM35H3P09UTC 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 480(RGB)×640 , VGA |
| zobrazovací mód | Buenaview, Normally Black, Transflective |
| aktivní oblast | 53.28×71.04 mm |
| obrys | 63.5×85×5.83 mm |
| povrch | Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.)(Transmissive)5.5:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 40/60 (Max.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 39 pins |
| vstupní napětí | 3.0/1.8V (Typ.)(VDD/VCCIO) |
| aplikace | HHP |
