| PartNumber | DLC0500AIG-2 |
| Značka | Other |
| Velikost | 5.0 |
| aplikace | VDP |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 400 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | DLC |
| panelový model | DLC0500AIG-2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 101.568×76.176 mm |
| obrys | 117.65×88.43×6 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193140% |
| Doba odezvy | 10/10 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.)(VCC) |
| aplikace | VDP |
