| PartNumber | DX08D11VM0AAA |
| Značka | KOE |
| Velikost | 3.0 |
| aplikace | MPH |
| Rozlišení | 480×800 |
| Složení | LCM |
| Jas | 400 |
| CR | 400:1 |
| Barvy | 262K/16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | HITACHI |
| panelový model | DX08D11VM0AAA |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 3.0 inch |
| rozlišení | 480(RGB)×800 , WVGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 38.88×64.8 mm |
| obrys | 45.6×76.4 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193171% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1S6PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6/8-bit) + SPI, 49 pins |
| vstupní napětí | 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| aplikace | MPH |
