| PartNumber | LS030B3UX01D |
| Značka | SHARP |
| Velikost | 3.0 |
| aplikace | MPH |
| Rozlišení | 240×400 |
| Složení | LCM |
| Jas | 400 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | CPU |
| značka panelu | SHARP |
| panelový model | LS030B3UX01D |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 3.0 inch |
| rozlišení | 240(RGB)×400 , WQVGA |
| zobrazovací mód | Normally Black |
| aktivní oblast | 38.88×64.8 mm |
| obrys | 45.08×75 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 500 : 1 (Typ.) |
| zobrazit barvy | 262K , CIE193175% |
| Doba odezvy | 11/24 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1S5PWLEDWithout Driver |
| signálové rozhraní | CPU, 40 pins |
| vstupní napětí | 1.8/2.8V (Typ.)(VDDIO/VCC) |
| aplikace | MPH |
