| PartNumber | E555HBM2 |
| Značka | EDO |
| Velikost | 5.5 |
| aplikace | MPH |
| Rozlišení | 720×1280 |
| Složení | OLED |
| Jas | 300 |
| CR | 3000:1 |
| Barvy | 16.7M |
| Podsvícení | self |
| Rozhraní | MIPI |
| značka panelu | EDO |
| panelový model | E555HBM2 |
| typ panelu | AM-OLED , OLED |
| velikost panelu | 5.5 inch |
| rozlišení | 720(RGB)×1280 , WXGA |
| aktivní oblast | 69.12×122.88 mm |
| obrys | 72.8×131.2 mm |
| povrch | |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 3000 : 1 (Min.) |
| zobrazit barvy | 16.7M (8-bit), CIE1931105% |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| řidič ic | COG Built-in SH1386 |
| signálové rozhraní | MIPI (4 data lanes), 30 pins |
| vstupní napětí | 3.3/4.6/6.1/-3.5V (Typ.)(VCI/VELVDD/VSP/VELVSS) |
| aplikace | MPH |
