| PartNumber | LH550WF4-SD01 |
| Značka | LG Display |
| Velikost | 5.5 |
| aplikace | MPH |
| Rozlišení | 1080×1920 |
| Složení | Assembly |
| Jas | 550 |
| CR | 1600:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LH550WF4-SD01 |
| typ panelu | LTPS TFT-LCD , Assembly |
| velikost panelu | 5.5 inch |
| rozlišení | 1080(RGB)×1920 , FHD |
| aktivní oblast | 68.364×121.536 mm |
| obrys | 75.27×155.55×2.35 mm |
| povrch | |
| jas | 550 cd/m² (Typ.) |
| kontrastní poměr | 1600:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | MIPI (4 data lanes), 36 pins |
| vstupní napětí | 1.8//5.7/-5.7V (Typ.)(DVDD/AVDDH/AVDDN) |
| aplikace | MPH |
