| PartNumber | G121X1-L03 |
| Značka | Innolux |
| Velikost | 12.1 |
| aplikace | CNS |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 600 |
| CR | 700:1 |
| Barvy | 262K/16.2M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | G121X1-L03 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 12.1 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 245.76×184.32 mm |
| obrys | 260.5×204×8.9 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 600 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 262K/16.2M (6-bit / 6-bit + FRC), CIE193163% |
| Doba odezvy | 5/11 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6/8-bit), 20 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VCC) |
| aplikace | CNS |
| AA121XH03 | Mitsubishi | 12.1 | 1024×768 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| G121X1-L03 | Innolux | 12.1 | 1024×768 |
| G121X1-L04 | Innolux | 12.1 | 1024×768 |
| G121XN01 V0 | AUO | 12.1 | 1024×768 |
| G121XTN01.0 | AUO | 12.1 | 1024×768 |
| LQ121S1LG61 | SHARP | 12.1 | 800×600 |
| LTN121W4-L01 | Samsung | 12.1 | 1280×800 |
| NL8060BC31-20 | NLT | 12.1 | 800×600 |
| TX31D41VM2BAA | KOE | 12.1 | 800×600 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| G121X1-L03 | Innolux | 12.1 | 1024×768 |
| LA080WV8-SL01 | LG Display | 8.0 | 800×480 |
| LQ058Y5DG30A | SHARP | 5.8 | 800×480 |
| PW065XS1 | E Ink | 6.5 | 400×234 |
| YX-CM043-QN05-56 | 4.3 | 480×272 |
