| PartNumber | CLAA050JA01CT |
| Značka | CPT |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 320 |
| CR | 350:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | CPT |
| panelový model | CLAA050JA01CT |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 110.88×62.832 mm |
| obrys | 120.7×75.8×4.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 320 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 10S1PWLEDWithout Driver |
| signálové rozhraní | TTL (1 ch, 8-bit), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
