| PartNumber | G190SF01 V0 |
| Značka | AUO |
| Velikost | 19.0 |
| aplikace | IA |
| Rozlišení | 1680×342 |
| Složení | LCM |
| Jas | 300 |
| CR | 2000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | G190SF01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch(1/3 cut of 22.0") |
| rozlišení | 1680(RGB)×342 |
| zobrazovací mód | P-MVA, Normally Black, Transmissive |
| aktivní oblast | 473.76×96.44 mm |
| obrys | 493.7×124.8×18.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 2000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S5PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | IA |
