| PartNumber | G104XVN01.0 |
| Značka | AUO |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 470 |
| CR | 3000:1 |
| Barvy | 262K/16.2M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | G104XVN01.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | PSA, Normally Black, Transmissive |
| aktivní oblast | 210.4×157.8 mm |
| obrys | 238.6×175.8×7 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 470 cd/m² (Typ.) |
| kontrastní poměr | 3000:1 (Typ.) |
| zobrazit barvy | 262K/16.2M (6-bit / 6-bit + FRC), CIE193160% |
| Doba odezvy | 20/10 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 stringsWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6/8-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
