| PartNumber | HSD089IFW1-A00 |
| Značka | HannStar |
| Velikost | 8.9 |
| aplikace | MP4 |
| Rozlišení | 1024×600 |
| Složení | LCM |
| Jas | 220 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HannStar |
| panelový model | HSD089IFW1-A00 8 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.9 inch |
| rozlišení | 1024(RGB)×600 , WSVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 195.072×113.4 mm |
| obrys | 213.36×129.55×5.45 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 5/20 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | MP4 |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| B089AW01 V2 | AUO | 8.9 | 1024×600 |
| HSD089IFW1-A00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW1-D00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| LTD089EXWF | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| N089A1-L01 | Innolux | 8.9 | 1280×768 |
| NL10260BC19-01D | NLT | 8.9 | 1024×600 |
| AT070TN93 V.2 | Innolux | 7.0 | 800×480 |
| CLAA070ND28CW | CPT | 7.0 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| ED070NA-01N | Innolux | 7.0 | 1024×600 |
| EE070NA-01D | Innolux | 7.0 | 1024×600 |
| HSD089IFW1-A00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW1-D00 | HannStar | 8.9 | 1024×600 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LW700AT9003 | Innolux | 7.0 | 800×480 |
