| PartNumber | HSD101PWW1-A00-C40 |
| Značka | HannStar |
| Velikost | 10.1 |
| aplikace | PAD |
| Rozlišení | 1280×800 |
| Složení | Assembly |
| Jas | 290 |
| CR | 800:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HannStar |
| panelový model | HSD101PWW1-A00-C40 |
| typ panelu | a-Si TFT-LCD , Assembly |
| velikost panelu | 10.1 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| aktivní oblast | 216.96×135.6 mm |
| povrch | |
| jas | 290 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193145% |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| TV101QUM-N00 | BOE | 10.1 | 3840×2160 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
