| PartNumber | HT170EX1-101 |
| Značka | BOE |
| Velikost | 17.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 300 |
| CR | 700:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | BOE |
| panelový model | HT170EX1-101 3 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 337.92×270.336 mm |
| obrys | 354.9×290.3×13.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC) |
| Doba odezvy | 2/6 (Typ.)(Tr/Td) |
| úhel pohledu | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| HT170E01-300 | BOE | 17.0 | 1280×1024 |
| HT170E02-100 | BOE | 17.0 | 1280×1024 |
| HT170EX1-101 | BOE | 17.0 | 1280×1024 |
| HT170EX1-300 | BOE | 17.0 | 1280×1024 |
| LM170E03-TLB1 | LG Display | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| MT170EN01 V.1 | Innolux | 17.0 | 1280×1024 |
| N170C3-L01 | Innolux | 17.0 | 1440×900 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| HR215WU1-120 | BOE | 21.5 | 1920×1080 |
| HT190WG3-100 | BOE | 19.0 | 1440×900 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| M190A1-L02 | Innolux | 19.0 | 1440×900 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
