| PartNumber | NL128102BC29-01C |
| Značka | NLT |
| Velikost | 19.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 270 |
| CR | 450:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL128102BC29-01C |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | SA-SFT, Normally Black, Transmissive |
| aktivní oblast | 376.32×301.056 mm |
| obrys | 404.2×330×25.55 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 270 cd/m² (Typ.) |
| kontrastní poměr | 450:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 10/10 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
| NL128102AC28-07 | NLT | 18.1 | 1280×1024 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01B | NLT | 19.0 | 1280×1024 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| LM230WF8-TLA2 | LG Display | 23.0 | 1920×1080 |
| LM250WW1-SSA1 | LG Display | 25.0 | 2560×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| M236HGJ-L11 | Innolux | 23.6 | 1920×1080 |
| TMS150XG1-10TB | Tianma | 15.0 | 1024×768 |
