| PartNumber | KCG075VG2BE-G00 |
| Značka | Kyocera |
| Velikost | 7.5 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 200 |
| CR | 30:1 |
| Barvy | Color |
| Podsvícení | CCFL |
| Rozhraní | Parallel Data |
| značka panelu | Kyocera |
| panelový model | KCG075VG2BE-G00 |
| typ panelu | CSTN-LCD , LCM |
| velikost panelu | 7.5 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | STN, Normally Black, Transmissive |
| aktivní oblast | 151.68×113.76 mm |
| obrys | 184×139.8×13.2 mm |
| povrch | Glare (Haze 0%) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 30:1 (Typ.) |
| zobrazit barvy | Color |
| Doba odezvy | 270/280 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvence | 75Hz |
| typ lampy | 2 pcsCCFLOptional |
| signálové rozhraní | Parallel Data (8-bit), 20 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VDD) |
| rohs: | |
| aplikace | IA |
