| PartNumber | L5S30883P00 |
| Značka | SANYO |
| Velikost | 4.5 |
| aplikace | CNS |
| Rozlišení | 480×240 |
| Složení | LCM |
| Jas | 400 |
| CR | 300:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SANYO |
| panelový model | L5S30883P00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.5 inch |
| rozlišení | 480(RGB)×240 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 99.36×56.04 mm |
| obrys | 112.7×70.2 mm |
| povrch | Glare (Haze 0%) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 10/20 (Typ.)(Tr/Td) |
| úhel pohledu | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| rohs: | |
| aplikace | CNS |
