| PartNumber | LA050WQ1-TD01 |
| Značka | LG Display |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 1100 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | LG Display |
| panelový model | LA050WQ1-TD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 110.88×62.478 mm |
| obrys | 124×75.2×8.3 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 1100 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193175% |
| Doba odezvy | 6/9 (Typ.)(Tr/Td) |
| úhel pohledu | 55/55/55/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 60 pins |
| vstupní napětí | 3.3/10.0V (Typ.)(DVDD/AVDD) |
| aplikace | CNS |
