| PartNumber | LTM04C380K |
| Značka | TOSHIBA |
| Velikost | 4.0 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 130 |
| CR | 250:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | TOSHIBA |
| panelový model | LTM04C380K |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 80.64×60.48 mm |
| obrys | 117.9×72.5×7.7 mm |
| povrch | |
| jas | 130 cd/m² (Typ.) |
| kontrastní poměr | 250:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 50/50 (Max.)(Tr/Td) |
| úhel pohledu | |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 27 pins |
| vstupní napětí | 3.3V (Typ.)(VDD) |
| aplikace | IA |
