| PartNumber | LM238WR2-SLA1 |
| Značka | LG Display |
| Velikost | 23.8 |
| aplikace | IA |
| Rozlišení | 3840×2160 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 1.07B |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LM238WR2-SLA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 23.8 inch |
| rozlišení | 3840(RGB)×2160 , UHD |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 527.04×296.46 mm |
| obrys | 545×323.4×14.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 1.07B (8-bit + Hi-FRC), sRGB |
| Doba odezvy | 14 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 16S4PWLEDWithout Driver |
| signálové rozhraní | LVDS (8 ch, 10-bit), 174 pins |
| vstupní napětí | 10.0V (Typ.) |
| aplikace | IA |
