| PartNumber | LM270WQ1-SDA2 |
| Značka | LG Display |
| Velikost | 27.0 |
| aplikace | DMPC |
| Rozlišení | 2560×1440 |
| Složení | LCM |
| Jas | 380 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | LG Display |
| panelový model | LM270WQ1-SDA2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 27.0 inch |
| rozlišení | 2560(RGB)×1440 , Quad-HD |
| zobrazovací mód | H-IPS, Normally Black, Transmissive |
| aktivní oblast | 596.736×335.664 mm |
| obrys | 630×376.13×22.3 mm |
| povrch | Glare (Haze 0%), Hard coating (2H), Antireflection |
| jas | 380 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), sRGB |
| Doba odezvy | 6.5/7.5 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 stringsWLEDWithout Driver |
| signálové rozhraní | eDP (4 Lanes), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
