| PartNumber | LQ097L1JY01A |
| Značka | SHARP |
| Velikost | 9.7 |
| aplikace | PAD |
| Rozlišení | 2048×1536 |
| Složení | LCM |
| Jas | 440 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | SHARP |
| panelový model | LQ097L1JY01A |
| typ panelu | IGZO TFT-LCD , LCM |
| velikost panelu | 9.7 inch |
| rozlišení | 2048(RGB)×1536 , QXGA |
| zobrazovací mód | O-mode FFS, Normally Black, Transmissive |
| aktivní oblast | 196.608×147.456 mm |
| povrch | Glare (Haze 0%), Hard coating (2H), Reflection 1.45% (Max.) |
| jas | 440 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S6P×2CNWLEDWithout Driver |
| signálové rozhraní | eDP (4 Lanes), 56 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
