| PartNumber | M070SW46 R0 |
| Značka | IVO |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 1200×1920 |
| Složení | LCM |
| Jas | 380 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | IVO |
| panelový model | M070SW46 R0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 1200(RGB)×1920 , WUXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 94.5×151.2 mm |
| obrys | 104×161.37×3.59 mm |
| povrch | Antiglare, Hard coating (3H), Antireflection |
| jas | 380 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193160% |
| Doba odezvy | 30 (Max.)(Tr+Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥100)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | MIPI (4 data lanes), 31 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
