| PartNumber | LQ104V1LG92 |
| Značka | SHARP |
| Velikost | 10.4 |
| aplikace | GM |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 330 |
| CR | |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ104V1LG92 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 240×179.2 mm |
| povrch | |
| jas | 330 cd/m² (Typ.) |
| kontrastní poměr | |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | |
| úhel pohledu | |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFL |
| signálové rozhraní | LVDS (1 ch, 8-bit) |
| aplikace | GM |
