| PartNumber | G104X1-L02 |
| Značka | Innolux |
| Velikost | 10.4 |
| aplikace | GM |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 400 |
| CR | 1200:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | G104X1-L02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 210.4×157.8 mm |
| obrys | 225.5×176.3×10.67 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193157% |
| Doba odezvy | 14/11 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | GM |
