| PartNumber | LQ140Z1JW01 |
| Značka | SHARP |
| Velikost | 14.0 |
| aplikace | NBPC |
| Rozlišení | 3200×1800 |
| Složení | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | SHARP |
| panelový model | LQ140Z1JW01 |
| typ panelu | IGZO TFT-LCD , LCM |
| velikost panelu | 14.0 inch |
| rozlišení | 3200(RGB)×1800 , Quad-HD+ |
| zobrazovací mód | Normally Black, Transmissive |
| aktivní oblast | 309.6×174.15 mm |
| obrys | 320.65×199.08×2.75 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Antiglare (Haze 42%) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S8PWLEDWithout Driver |
| signálové rozhraní | eDP (4 Lanes), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
