| PartNumber | LQ156T3LW02 |
| Značka | SHARP |
| Velikost | 15.6 |
| aplikace | GM |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 400 |
| CR | |
| Barvy | 16.2M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ156T3LW02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.6 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | ASV, Normally Black, Transmissive |
| aktivní oblast | 344.232×193.536 mm |
| obrys | 363.8×215.9 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193176% |
| Doba odezvy | |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 8-bit) |
| aplikace | GM |
