| PartNumber | LQ170K1LW02 |
| Značka | SHARP |
| Velikost | 17.0 |
| aplikace | GM |
| Rozlišení | 1280×768 |
| Složení | LCM |
| Jas | 300 |
| CR | 600:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ170K1LW02 3 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1280(RGB)×768 , WXGA |
| zobrazovací mód | P-MVA, Normally Black, Transmissive |
| aktivní oblast | 369.6×221.76 mm |
| obrys | 413.8×259×16 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC) |
| Doba odezvy | 20 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 20 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | GM |
