| PartNumber | LS027B7DH01 |
| Značka | SHARP |
| Velikost | 2.7 |
| aplikace | HHP |
| Rozlišení | 400×240 |
| Složení | LCM |
| Jas | |
| CR | |
| Barvy | Monochrome |
| Podsvícení | No B/L |
| Rozhraní | SPI |
| značka panelu | SHARP |
| panelový model | LS027B7DH01 |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 2.7 inch |
| rozlišení | 400×240 , WQVGA |
| zobrazovací mód | Transflective |
| aktivní oblast | 58.8×35.28 mm |
| obrys | 62.8×42.82 mm |
| povrch | Hard coating (3H) |
| jas | |
| kontrastní poměr | 14:1 (Typ.)(Reflective) |
| zobrazit barvy | Monochrome (1-bit) |
| Doba odezvy | 10/20 (Typ.)(Tr/Td) |
| úhel pohledu | 55/55/60/60 (Min.)(CR≥2)(L/R/U/D) |
| typ lampy | No B/L |
| signálové rozhraní | SPI, 10 pins |
| vstupní napětí | 5.0/5.0V (Typ.)(VDD/VDDA) |
| aplikace | HHP |
| LQ027A3DA01 | SHARP | 2.7 | 320×240 |
| LS027B4DH01 | SHARP | 2.7 | 400×240 |
| LS027B7DH01 | SHARP | 2.7 | 400×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| OEL9M0065-G-E | Other | 2.7 | 256×64 |
| OEL9M0065-W-E | Other | 2.7 | 256×64 |
| OEL9M5003-R-E | Other | 2.7 | 128×64 |
| UG-2864ASGIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASWIG01 | WiseChip | 2.7 | 128×64 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
| 28QVF1J | SII | 2.8 | 240×320 |
| 32WVF0H | SII | 3.2 | 480×800 |
| COM22H2P16ULC | ORTUSTECH | 2.2 | 240×320 |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LQ038Q7DB03A | SHARP | 3.8 | 240×320 |
| LQ040Y3DX80 | SHARP | 4.0 | 480×800 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
| TX09D70VM1CEA | KOE | 3.5 | 240×320 |
