| PartNumber | LQ040Y3DX80 |
| Značka | SHARP |
| Velikost | 4.0 |
| aplikace | HHP |
| Rozlišení | 480×800 |
| Složení | LCM |
| Jas | 320 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ040Y3DX80 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 480(RGB)×800 , WVGA |
| zobrazovací mód | New Mode2, Normally Black, Transmissive |
| aktivní oblast | 51.84×86.4 mm |
| obrys | 57.14×96.85×2 mm |
| povrch | |
| jas | 320 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 40 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| vstupní napětí | 2.8/1.8V (Typ.)(VCI/IOVCC) |
| aplikace | HHP |
