| PartNumber | LS028B8PX05 |
| Značka | SHARP |
| Velikost | 2.8 |
| aplikace | MPH |
| Rozlišení | 240×400 |
| Složení | LCM |
| Jas | 280 |
| CR | 500:1 |
| Barvy | 4096 |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LS028B8PX05 |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 2.8 inch |
| rozlišení | 240(RGB)×400 , WQVGA |
| zobrazovací mód | ASV, Normally Black, Transflective |
| aktivní oblast | 36×60 mm |
| obrys | 41.2×69.28×1.7 mm |
| povrch | Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| zobrazit barvy | 4096 |
| Doba odezvy | 13/30 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥2)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1S5PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 4-bit), 29 pins |
| vstupní napětí | 10.6/-5.3V (Typ.)(VDD/GVSS) |
| aplikace | MPH |
