| PartNumber | LTP280QV-E01 |
| Značka | Samsung |
| Velikost | 2.8 |
| aplikace | MPH |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 110 |
| CR | 150:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SAMSUNG |
| panelový model | LTP280QV-E01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.8 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 43.2×57.6 mm |
| obrys | 52.9×71.7×4.75 mm |
| povrch | Hard coating (3H) |
| jas | 110 cd/m² (Typ.) |
| kontrastní poměr | 150:1 (Typ.)(Transmissive)6:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit), CIE193130% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 50/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 61 pins |
| vstupní napětí | 3.3/5.0/15/-10V (Typ.)(DVDD/AVDD/VON/VOFF) |
| aplikace | MPH |
