| PartNumber | UG-5664ALBDF01 |
| Značka | WiseChip |
| Velikost | 2.8 |
| aplikace | IA |
| Rozlišení | 256×64 |
| Složení | OLED |
| Jas | 80 |
| CR | 2000:1 |
| Barvy | Mono(Blue) |
| Podsvícení | self |
| Rozhraní | CPU/SPI |
| značka panelu | Univision |
| panelový model | UG-5664ALBDF01 |
| typ panelu | PM-OLED , OLED |
| velikost panelu | 2.8 inch |
| rozlišení | 256×64 |
| aktivní oblast | 69.104×17.264 mm |
| obrys | 84×25.8×2.1 mm |
| povrch | |
| jas | 80 cd/m² (Typ.) |
| kontrastní poměr | 2000 : 1 (Typ.) |
| zobrazit barvy | Mono(Blue) |
| úhel pohledu | 80/80/80/80 (Min.)(L/R/U/D) |
| řidič ic | COF Built-in SSD1322 |
| signálové rozhraní | 8-bit 6800/8080 parallel, 4-wire SPI, 30 pins |
| vstupní napětí | 2.8/12V (Typ.)(VCI/VCC) |
| rohs: | |
| aplikace | IA |
| 28QVF1J | SII | 2.8 | 240×320 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| UG-5664ALBDF01 | WiseChip | 2.8 | 256×64 |
| UG-5664ALBEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASGEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASGGF01 | WiseChip | 5.5 | 256×64 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASYEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| EL320.240.36 IN | Lumineq | 5.7 | 320×240 |
| G190SVT01.0 | AUO | 19.0 | 1680×342 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| SX21V001-Z4A | KOE | 8.2 | 640×480 |
| TM24064BBCWVBYD | Tianma | 5.2 | 240×64 |
| UG-2832TSWGG01 | WiseChip | 1.0 | 128×32 |
| UG-2864KSWMG01 | WiseChip | 1.54 | 128×64 |
