| PartNumber | LS050T1SX06 |
| Značka | SHARP |
| Velikost | 5.0 |
| aplikace | MPH |
| Rozlišení | 1080×1920 |
| Složení | LCM |
| Jas | 480 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | SHARP |
| panelový model | LS050T1SX06 |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 1080(RGB)×1920 , FHD |
| zobrazovací mód | New Mode2, Normally Black, Transmissive |
| aktivní oblast | 61.884×110.016 mm |
| obrys | 64.3×116.6×1.5 mm |
| povrch | |
| jas | 480 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193171% |
| Doba odezvy | 35 (Max.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 34 pins |
| vstupní napětí | 1.8/5.0/-5.0V (Typ.)(IOVDD/VSP/VSN) |
| aplikace | MPH |
