| PartNumber | LT085AC18N00 |
| Značka | TOSHIBA |
| Velikost | 8.5 |
| aplikace | IA |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | |
| CR | 300:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | Toshiba Mobile Display |
| panelový model | LT085AC18N00 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 8.5 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 184.8×110.88 mm |
| povrch | |
| jas | |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 50/50 (Max.)(Tr/Td) |
| úhel pohledu | 55/55/60/35 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| rohs: | |
| aplikace | IA |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| LT084AC27800 | TOSHIBA | 8.4 | 800×600 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| MAA121DSK26 | Mitsubishi | 12.1 | 800×600 |
| MD640.400-54 | FINLUX | 9.1 | 640×400 |
| NL6448BC33-50 | NLT | 10.4 | 640×480 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
