| PartNumber | LT101MB02000 |
| Značka | JDI |
| Velikost | 10.1 |
| aplikace | PAD |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 340 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | JDI |
| panelový model | LT101MB02000 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.1 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | Normally Black, Transmissive |
| aktivní oblast | 217.44×135.9 mm |
| obrys | 228.1×147.5×3.89 mm |
| povrch | Antiglare |
| jas | 340 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193160% |
| Doba odezvy | 60/40 (Max.)(Tr/Td) |
| úhel pohledu | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5 stringsWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
