| PartNumber | LTL089CL02-002 |
| Značka | Samsung |
| Velikost | 8.9 |
| aplikace | PAD |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 450 |
| CR | 900:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | SAMSUNG |
| panelový model | LTL089CL02-002 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.9 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 191.52×119.7 mm |
| obrys | 203.5×135.9×5.2 mm |
| povrch | Glare (Haze 0%), Hard coating (2H) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S5PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 45 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
