| PartNumber | M270HW02 V3 |
| Značka | AUO |
| Velikost | 27.0 |
| aplikace | DMPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 300 |
| CR | 5000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | M270HW02 V3 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 27.0 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | VA, Normally Black, Transmissive |
| aktivní oblast | 597.6×336.15 mm |
| obrys | 630×368.2×10.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 5000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 7/5 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | 17S4PWLEDWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270HW01 V1 | AUO | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| IAQX10M | IDTech | 15.0 | 2048×1536 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| LTM190ET01 | Samsung | 19.0 | 1280×1024 |
| LTM230HT05 | Samsung | 23.0 | 1920×1080 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
