| PartNumber | MT185WHM-N10 |
| Značka | BOE |
| Velikost | 18.5 |
| aplikace | DMPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 200 |
| CR | 600:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | BOE |
| panelový model | MT185WHM-N10 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 18.5 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 409.8×230.4 mm |
| obrys | 430.4×254.6×11.4 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 1.5/3.5 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/25/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| HK185LEDM-CH25H | Other | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| MT185WHM-N10 | BOE | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM215DT7A | PANDA | 21.5 | 1920×1080 |
| LM230WF5-TRA1 | LG Display | 23.0 | 1920×1080 |
| LQ14D412 | SHARP | 13.8 | 640×480 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| M200HJJ-P01 | Innolux | 19.5 | 1920×1080 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| SVA190WX05TB | SVA-NEC | 19.0 | 1440×900 |
