| PartNumber | NL128102AC28-07 |
| Značka | NLT |
| Velikost | 18.1 |
| aplikace | IA |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 240 |
| CR | 300:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL128102AC28-07 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 18.1 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | A-SFT, Normally Black, Transmissive |
| aktivní oblast | 359.04×287.232 mm |
| obrys | 389×317.2×31.3 mm |
| povrch | Hard coating (2H), Antireflection |
| jas | 240 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193160% |
| Doba odezvy | 15/14 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 50 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | IA |
