| PartNumber | NL192108AC10-01D |
| Značka | NLT |
| Velikost | 9.0 |
| aplikace | IA |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 400 |
| CR | 700:1 |
| Barvy | 262K/16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | NLT |
| panelový model | NL192108AC10-01D |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 9.0 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | UA-SFT, Normally Black, Transmissive |
| aktivní oblast | 198.72×111.78 mm |
| obrys | 214.6×130×9.6 mm |
| povrch | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 13/12 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 6/8-bit), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
