| PartNumber | NL204153AC21-22 |
| Značka | NLT |
| Velikost | 21.3 |
| aplikace | MD |
| Rozlišení | 2048×1536 |
| Složení | LCM |
| Jas | 800 |
| CR | 1400:1 |
| Barvy | 1.07B |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | NLT |
| panelový model | NL204153AC21-22 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.3 inch |
| rozlišení | 2048(RGB)×1536 , QXGA |
| zobrazovací mód | UA-SFT, Normally Black |
| aktivní oblast | 433.152×324.864 mm |
| obrys | 457×350×23 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 800 cd/m² (Typ.) |
| kontrastní poměr | 1400 : 1 (Typ.) |
| zobrazit barvy | 1.07B (10-bit), CIE193172% |
| Doba odezvy | 20/20 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (4 ch, 10-bit), 104 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | MD |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07A | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| TX54D22VC0CAB | KOE | 21.3 | 1024×768 |
| ITSX88E | IDTech | 18.1 | 1280×1024 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| LQ201U1LW18 | SHARP | 20.1 | 1600×1200 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R300SFE-L02 | Innolux | 30.0 | 3280×2048 |
| VVX28T143H00 | Panasonic | 28.0 |
