| PartNumber | NL160120AC27-32B |
| Značka | NLT |
| Velikost | 21.3 |
| aplikace | MD |
| Rozlišení | 1600×1200 |
| Složení | LCM |
| Jas | 760 |
| CR | 1200:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL160120AC27-32B |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.3 inch |
| rozlišení | 1600(RGB)×1200 , UXGA |
| zobrazovací mód | UA-SFT, Normally Black, Transmissive |
| aktivní oblast | 432×324 mm |
| obrys | 457×350×23 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 760 cd/m² (Typ.) |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 20/20 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | MD |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
| ITQX21K | IDTech | 20.8 | 2048×1536 |
| ITSX88E | IDTech | 18.1 | 1280×1024 |
| LQ201U1LW31 | SHARP | 20.1 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
| VVX28T143H00 | Panasonic | 28.0 |
