| PartNumber | NL256204AM15-02A |
| Značka | NLT |
| Velikost | 20.1 |
| aplikace | DMPC |
| Rozlišení | 2560×2048 |
| Složení | LCM |
| Jas | 850 |
| CR | 600:1 |
| Barvy | Grayscale |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL256204AM15-02A |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 20.1 inch |
| rozlišení | 2560(LCR)×2048 , QSXGA |
| zobrazovací mód | SA-SFT, Normally Black, Transmissive |
| aktivní oblast | 399.36×319.49 mm |
| obrys | 423.4×343.5×45.5 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 850 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | Grayscale (8-bit) |
| Doba odezvy | 15/15 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (4 ch, 8-bit) |
| vstupní napětí | 12.0V (Typ.) |
| rohs: | |
| aplikace | DMPC |
