| PartNumber | NL6448BC33-46 |
| Značka | NLT |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 350 |
| CR | 300:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | NEC |
| panelový model | NL6448BC33-46 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 243×185.1×11.5 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193143% |
| Doba odezvy | 6/40 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6-bit), 31 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VCC) |
| aplikace | IA |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448BC20-18D | NLT | 6.5 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
| NL6448BC28-01 | NLT | 9.0 | 640×480 |
| NL6448BC33-46 | NLT | 10.4 | 640×480 |
| NL6448BC33-54 | NLT | 10.4 | 640×480 |
| NL6448BC33-64D | NLT | 10.4 | 640×480 |
| NL6448BC33-64E | NLT | 10.4 | 640×480 |
| G150XG01 V4 | AUO | 15.0 | 1024×768 |
| LQ104V1DC31 | SHARP | 10.4 | 640×480 |
| LQ121S1DG21A | SHARP | 12.1 | 800×600 |
| LTB190E3-L01 | Samsung | 19.0 | 1280×1024 |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| M121GNX2 R1 | IVO | 12.1 | 1024×768 |
| MD480T640PG3 | Panasonic | 11.3 | 640×480 |
| OEL9M0073-R-E | Other | 1.0 | 128×64 |
| TM150XG-A02-01 | SANYO | 15.0 | 1024×768 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
