| PartNumber | TD035SHED1 |
| Značka | TPO |
| Velikost | 3.5 |
| aplikace | MPH |
| Rozlišení | 480×640 |
| Složení | LCM |
| Jas | 170 |
| CR | 200:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | TPO |
| panelový model | TD035SHED1 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 480(RGB)×640 , VGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 53.28×71.04 mm |
| obrys | 64×85 mm |
| povrch | |
| jas | 170 cd/m² (Typ.) |
| kontrastní poměr | 200:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit), CIE193137% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 51 pins |
| vstupní napětí | 3.0/3.0V (Typ.)(VDC/VDDIO) |
| aplikace | MPH |
