| PartNumber | TM047XDZP02 |
| Značka | Tianma |
| Velikost | 4.7 |
| aplikace | MPH |
| Rozlišení | 540×960 |
| Složení | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | TIANMA |
| panelový model | TM047XDZP02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.7 inch |
| rozlišení | 540(RGB)×960 , qHD |
| zobrazovací mód | SFT, Normally Black, Transmissive |
| aktivní oblast | 58.32×103.68 mm |
| obrys | 62.72×113.53×1.78 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 24 pins |
| vstupní napětí | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplikace | MPH |
| A047FW01 V0 | AUO | 4.7 | 480×272 |
| DX12D100VM0EAA | JDI | 4.7 | 720×1280 |
| LM32010P | SHARP | 4.7 | 320×240 |
| LM32K101 | SHARP | 4.7 | 320×240 |
| LQ047K3SX06 | SHARP | 4.7 | 720×1280 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM047NBH03 | Tianma | 4.7 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| H650DAN01.0 | AUO | 6.4 | 1080×1920 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LH520WF3-SH02 | LG Display | 5.2 | 1080×1920 |
| LQ020B3DC01 | SHARP | 2.0 | 176×220 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| TM018FDZ12 | Tianma | 1.8 | 128×160 |
| TM020HDZ05 | Tianma | 2.0 | 240×320 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
