| PartNumber | LQ020B3DC01 |
| Značka | SHARP |
| Velikost | 2.0 |
| aplikace | MPH |
| Rozlišení | 176×220 |
| Složení | LCM |
| Jas | 300 |
| CR | 350:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ020B3DC01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.0 inch |
| rozlišení | 176(RGB)×220 , QCIF+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 31.68×39.6 mm |
| obrys | 37.8×53×2.9 mm |
| povrch | |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193160% |
| Doba odezvy | 10/25 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 39 pins |
| vstupní napětí | 2.85/2.85V (Typ.)(VDDIO/VCI) |
| aplikace | MPH |
| 20QVF0H | SII | 2.0 | 240×320 |
| A020BL01 V0 | AUO | 2.0 | 640×240 |
| LB020Q01-A1 | LG Display | 2.0 | 320×240 |
| LQ020B3DC01 | SHARP | 2.0 | 176×220 |
| LS020A8DX02 | SHARP | 2.0 | 320×240 |
| LS020B8UD02 | SHARP | 2.0 | 176×220 |
| LTM020A52A | TOSHIBA | 2.0 | 240×320 |
| OEL9M0064-R-E | Other | 2.0 | 128×32 |
| OEL9M0064-Y-E | Other | 2.0 | 128×32 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| ACX450AKN-7 | JDI | 5.0 | 1080×1920 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LMS320HF46 | Samsung | 3.2 | 240×432 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
| TX09D83VM3CEA | KOE | 3.5 | 240×320 |
