| PartNumber | TM080VDSP01 |
| Značka | Tianma |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 1200×1920 |
| Složení | LCM |
| Jas | 390 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | TIANMA |
| panelový model | TM080VDSP01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.0 inch |
| rozlišení | 1200(RGB)×1920 , WUXGA |
| zobrazovací mód | SFT, Normally Black, Transmissive |
| aktivní oblast | 107.64×172.224 mm |
| obrys | 114.6×184.1×2.3 mm |
| povrch | |
| jas | 390 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193160% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S3PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 31 pins |
| vstupní napětí | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikace | PAD |
